E42 Dry / Wet Inlay
1. multi-tag identification, identification tag
2. high sensitivity, high security performance, has Korfball unique identifier (TID code)
3. using various materials (copper paper, PET, thermal paper, DuPont paper, PP synthetic paper ) package
|
● Basic Parameters |
|
| Types of | UHF passive RFID tags |
| Working Frequency | 860-960MHz |
|
Protocol |
ISO / IEC 18000-6C EPC Class1 Gen2 |
|
● Physical Parameters |
|
| Size |
68 * 19mm |
| Packaging Materials | PET + etched aluminum antenna |
| Antenna | Etching aluminum |
| Craft | None |
|
● Performance Parameters |
|
| Chip | impinjM4D / M4E / M4QT |
| Storage | With integrated chip-related |
| Working Mode | read and write |
| Data Retention | > 10 years |
| Write Endurance | 100,000 times |
| Reading Distance | 0-10m (the reading range is related to the working condition and reader) |
|
● Environmental Parameters |
|
| Working temperature | (-25 ℃ ~ + 55 ℃) |
| Storage temperature | (-30 ℃ ~ + 65 ℃) |
|
● Typical Applications |
|
| Applications | logistics and transport assets management , Retail management, Pharmaceuticals ,management, Supply chain management |
|
● Package |
|
| Packaging Information | Piece/Roll |
