Plotter Cutting Engineer Grade Reflective Vinyl

Plotter Cutting Engineer Grade Reflective Vinyl
Face Film 50 mics PET
Film Thickness 120 mics
AVG(RA) ≥25 CIL/㎡
Durability 3 years Outdoor
Width up to 124cm, can be customized
Release Liner 130 gram
Feature Plotter cutting, Die cutting

Plotter Cutting Engineer Grade Reflective Vinyl TN9020 reflective films Description

TN9020 PET Engineer Grade UV digital print Reflective Sheeting is an enclosed beaded retroreflective sheeting which consists of retroreflective glass beads sealed onto a PET substrate. It is suitable for plotter cutting and UV digital print. Please do not use it for screen print, normal digital print etc.

Technical Data

  • Retroreflective Elements: enclosed glass beaded
  • Durabilty: 3 years durability outdoor
  • Roll Sizes: 1.24M (W) x 45.7M, 48” (W) x 50 yards
  • Minimum Coefficient of Retroreflection (cd/lx/m2)
Color White Yellow Orange Red Green Blue Brown Black
0.2/4 25 20 18 10 8 3.5 1 0.1

* Test by Roadmaster according to ASTM D4956

  • Film Thickness: 120mic
  • Face Film: 50 mics PET
  • Adhesive: 30 mics permanent pressure sensitive adhesive
  • Release Liner: 130 GSM Poly coated paper liner (white or yellow)
  • Application Surface: Flat surface only such as aluminum
  • Application Temperature: 18-28℃ by any of the following methods:
    • Mechanical squeeze roll applicator
    • Hand squeeze roll applicator
    • Hand application is recommended for copy only

Leading Time

  • We have regular stock in the warehouse, otherwise, it will take 7-10 days upon deposits receive. Please confirm with us before ordering.

OEM & ODM

  • For order less than 100 rolls, we can do OEM Carton and Product mark
  • For order more than 100 rolls, and request your own logo, it needs one more deposit.

Quality Inspection

  • Raw material inspection: From face film to release paper, all the material will be strictly inspected before putting into production. We only use Qualified raw materials;
  • Production inspection: QC will cut production samples, bring it to our own lab then inspect brightness, stretch, thickness, etc.,also they will bring Brightness detector to production line and check for brightness.
  • Final inspection:We will sample test the final product, and also do inspection under client’s requested.

Package

  • Inner packing: PET inner film + Plastic Bag + 2 pc Plastic Plug
  • Outer packing: 5 layers carton box with carton sealing nail
Model Size (M) Carton (M) N.W.  (KG) G.W. (KG) 20GP  (Roll)
TN9020 1.24*45.7 1.31*0.21*0.24 19.6 23 360
  • *This data only for reference
  • *Please contact our staff for customized products.
  • *The data included the pallets size, we recommended to use pallets for protect the engineering grade goods as it’s very heavy.
  • Loading Port:Shenzhen or other China port

Storage

  • Reflective Sheeting must be used within 1 year after the date of receipt from Tanatt;
  • Please use PET inner film to tightly packed partially used Rolls, then return it back to the shipping carton. Vertically placed it can avoid distortion due to substrate buckling or extension due to moisture absorption, and avoid pressure that may damage the reflective layer.
  • Store the sheeting in a clean, dry area at 20 ℃ and 50% relative humidity and away from direct sunlight;
